Human step-up approval for agent actions: CIBA

Some actions should never ride on a token an agent already holds. Issuerd implements Client-Initiated Backchannel Authentication (CIBA, poll mode) so an agent can escalate a single action to the human behind it: the user sees an explicit approval request with a binding message, and only an approval mints a short-lived, DPoP-bound step-up token carrying the privileged scope.

Why agents need step-up
Issuerd’s CIBA at a glance
The step-up pattern
Walkthrough
Exact MCP operation approval
Recorded demo
Limits and notes
Source map

Why agents need step-up

Least privilege is not only about what a token can do — it is about when the authority exists at all. An autonomous agent that can list orders should not permanently hold the power to refund them. The healthy shape is:

The everyday login token carries no privileged scope. refunds:execute exists nowhere in the agent’s standing credentials.
When a task crosses a policy line the agent itself defined (“refunds above $100 need a human”), the agent asks the identity provider to interrupt the user.
The user approves or denies, with the action spelled out in a binding message they actually read — not a generic consent screen.
Only then does a token carrying refunds:execute come into existence: a short lifetime (the realm’s access-token lifespan, 300 s by default), bound to the agent’s DPoP key, usable for exactly the approved action.

This is CIBA’s consumption-device/authorization-device split applied to agents: the agent is the consumption device, the user’s browser session is the authorization device, and the binding message is the contract between them. It is also the practical shape of the human-in-the-loop (HITL) control that agent governance frameworks require for high-risk operations — with the important property that approval is gated by deterministic policy (the privileged scope simply does not exist before approval), not by the agent’s own judgment about when to ask.

Issuerd’s CIBA at a glance


Backchannel authentication endpoint	`POST /realms/{realm}/protocol/openid-connect/ext/ciba/auth` (advertised in discovery as `backchannel_authentication_endpoint`)
User approval endpoint	`POST /realms/{realm}/protocol/openid-connect/ext/ciba/approve` (browser form POST under the user’s SSO session)
Token polling	`grant_type=urn:openid:params:grant-type:ciba` with `auth_req_id` at the realm token endpoint
Delivery modes	poll only; ping and push are out of scope

Authentication request parameters (parsed in crates/issuerd-protocol/src/ciba.rs):

Parameter	Semantics
`scope`	Optional; when present, every scope must be assigned to the client (default or optional), otherwise `invalid_scope` — a client cannot pick up authority the admin never granted it
`login_hint` / `login_hint_token` / `id_token_hint`	At least one required, identifying the user to interrupt. User resolution currently honors `login_hint` (the username) only — a request carrying just one of the other hints parses but then fails with `400 unknown_user_id`
`binding_message`	Up to 100 characters; shown to the user at approval time and echoed in the flow — “Refund $150 for order #123”, not “Approve request”
`requested_expiry`	Overrides the default 120 s lifetime of the pending request
`acr_values`, `user_code`, `client_notification_token`	Parsed per the spec (the notification token matters for ping/push, which are not implemented)

Polling semantics, per the spec:

A pending request answers authorization_pending; polling faster than the advertised interval (default 5 s) answers slow_down; user denial answers access_denied.
Only the client that initiated the request may poll it (CIBA §7.1) — another client presenting the auth_req_id is rejected.
A disabled client cannot start backchannel authentication at all.

DPoP threading. When the polling request carries a DPoP proof, the issued step-up token is bound to that proof key (cnf.jkt) — the same binding discipline as every other grant. The privileged token is sender-constrained for its entire (short) lifetime. From there it feeds straight into the RFC 8693 exchange: step-up token in, aud = mcp-server, scope = "refunds:execute" token out, still DPoP-bound.

The step-up pattern

The configuration that makes the story hold together:

Assign the privileged scope (refunds:execute) to the agent’s client as an optional scope — and never request it at ordinary login. The login token then provably lacks it.
Assign the same scope to the downstream resource’s client (e.g. mcp-server) so a step-up token can be exchanged into that audience.
Encode the autonomy policy in the agent (“refunds above $100 need approval”), and encode the enforcement in the resource server (refund_order requires refunds:execute or answers 403 insufficient_scope). The agent’s policy is a convenience; the resource’s check is the guarantee.
Use a binding message that names the action, amount, and target. The user approves a specific decision, not a category.

Walkthrough

# 1. The agent starts backchannel authentication (client-authenticated).
curl -X POST \
  https://idp.example.com/realms/myrealm/protocol/openid-connect/ext/ciba/auth \
  -d client_id=app8-chat -d client_secret=<secret> \
  -d scope="openid refunds:execute" \
  -d login_hint=alice \
  -d binding_message="Refund $150 for order #123"
# → {"auth_req_id":"f1b56bd6-…","expires_in":120,"interval":5}

# 2. Alice's browser (SSO session cookie) approves or denies:
curl -b "issuerd_session_<realm>=…" -X POST \
  https://idp.example.com/realms/myrealm/protocol/openid-connect/ext/ciba/approve \
  -d auth_req_id=f1b56bd6-… -d action=approve

# 3. The agent polls with a DPoP proof until approval lands.
curl -u app8-chat:<secret> -X POST \
  https://idp.example.com/realms/myrealm/protocol/openid-connect/token \
  -H "DPoP: <proof for POST .../token>" \
  -d grant_type=urn:openid:params:grant-type:ciba \
  -d auth_req_id=f1b56bd6-…
# pending → {"error":"authorization_pending"}
# approved → access_token: scope="openid refunds:execute", cnf.jkt=<proof key>, expires_in=300  # realm access-token lifespan
# denied  → {"error":"access_denied"}

# 4. Exchange the step-up token into the MCP audience (see agentic-iam-mcp.md)
#    and call refund_order with it. When the token expires, the authority is gone.

Exact MCP operation approval

The realm-scoped MCP administration endpoint also has a strict CIBA profile for irreversible and high-impact operations. It is separate from the legacy scope-based example above and is disabled by default. Enable it only after every node supports the operation and approval routes:

[mcp]
enabled = true

[mcp.step_up]
enabled = true

The flow binds approval to an exact typed operation, not just a scope:

An ordinary DPoP token with mcp:write and the necessary manage role calls a strict tool. Issuerd stores a five-minute pending operation containing the canonical arguments and expected mutation state, then returns step_up_required with an operation ID and server-generated binding message.
A confidential client initiates CIBA with that ID, the exact MCP resource, login_hint, the returned binding message, and scope="openid mcp:step_up". The response includes an approval_url whose ID is independent of auth_req_id.
The hinted user authenticates freshly before any details are rendered. The server displays the exact escaped arguments and expected mutation, checks preconditions on GET and POST, and accepts one CSRF-protected decision. The legacy JSON approval endpoint cannot be used as a bypass.
The client polls with the original DPoP key and exact resource. Approval and polling share a per-request serialization lock, so the decision cannot erase polling history or reset the pacing interval. The client receives only an openid mcp:step_up DPoP token, never a refresh token. The durable grant lasts at most two minutes and cannot outlive the pending operation.
The client repeats the exact tool call. Issuerd atomically consumes the grant, checks current-state preconditions, commits the mutation, and stores the redacted result. Changed arguments are rejected. A changed precondition is a definite 409; an unknown outcome is retryable and never causes blind re-execution or an automatic fresh approval.

The step-up token cannot perform unrelated MCP calls or access UserInfo, Account, or Admin APIs. An exact repeat reconciles the stored result without a second mutation. acr_values=0 is supported; other requested contexts are rejected explicitly. Bearer compatibility cannot create or execute strict operations.

Returning to the client after approval

A confidential client may include an optional return_to in operation-bound CIBA initiation. It must exactly match one of the client’s registered redirect_uris; arbitrary or merely same-origin URLs are rejected with invalid_request. After approval or denial, Issuerd answers HTTP 303 to that registered URI, while clients without return_to keep the existing static decision page. The destination is checked again at decision time, so changing the client registration cannot turn this into an open redirect. The approval page adds only that validated destination’s origin to CSP form-action, rather than blocking a registered cross-origin return or allowing arbitrary sources. The remaining default-src 'none', frame-ancestors 'none', and base-uri 'none' restrictions are unchanged.

This preserves the five-minute pending-operation and fresh-authentication windows and the at-most-two-minute execution grant. It also supports a same-tab approval flow without hidden iframes, window.close(), or moving the trusted exact-operation approval page into an untrusted agent application.

Run the real TypeScript confidential profile and three-node approval flow:

./examples/mcp-admin/scripts/e2e-local.sh
./examples/mcp-admin/scripts/e2e-compose.sh
./examples/mcp-admin/scripts/e2e-step-up-cluster.sh

The cluster runner deliberately places approval on node 2, polling on node 3, and final execution on node 1 while preserving one canonical resource and DPoP key. See MCP server and examples/mcp-admin/ for the full operator and client contracts.

Recorded demo

The full loop — a refund request that exceeds the agent’s autonomous limit, the in-app approval card backed by a real CIBA flow, the DPoP-bound step-up token, and the same call without step-up dying with a real 403 — recorded against a live Issuerd lab rig:

Issuerd CIBA demo: human step-up approval, DPoP-bound step-up token, 403 without it

“Refund $150 for order #123” — over the agent’s $100 autonomous limit, so it starts CIBA with binding_message = "Refund $150 for order #123", scope = "openid refunds:execute" (trace shows auth_req_id, expires_in: 120, interval: 5).
Approval — the user clicks Approve on the in-app card; the approval rides the existing SSO session. The next poll returns a step-up token: scope = "openid refunds:execute", DPoP-bound, with the realm’s access-token lifespan as TTL (300 s by default).
Refund executed — the agent exchanges the step-up token into aud = mcp-server and the MCP server applies the refund; order #123 flips to refunded.
The control — a bare curl calling refund_order with the ordinary (non-step-up) token: HTTP/1.1 403, error="insufficient_scope", scope="refunds:execute". No human said yes, so no such authority exists.

Limits and notes

Poll mode only. CIBA ping and push delivery are deliberately out of scope (see Project Scope in the README); client_notification_token is parsed but no outbound notification is attempted.
Pending requests live in the distributed cache (ciba:{auth_req_id}) with their expiry as TTL — they work across a cluster and disappear on their own. An unknown, cross-client, or redeemed auth_req_id answers invalid_grant at polling; actual expiry answers expired_token. The legacy approval endpoint uses its corresponding expired/unknown-request rejection, while operation-bound approval uses the separate exact-operation page.
The approval endpoint is a browser form POST under the realm SSO session; it is same-site by design (the session cookie is SameSite=Lax), which is what allows in-app approval cards on sibling subdomains without any CORS surface.
Every CIBA decision is auditable through the realm’s login events (recorded by default): ciba_auth when a backchannel request is accepted (details carry the scope, expiry, and the binding message’s length — never the message text, which can carry PII), ciba_auth_error for rejections (invalid_scope, disabled or unknown client, missing hint, unknown/expired auth_req_id at approval, cross-user approval attempts), ciba_approve / ciba_deny for the user’s decision, and a login event with details.method=ciba when a poll mints the tokens. A denied or expired poll records login_error with access_denied / expired_token; authorization_pending and slow_down polls are protocol chatter and record nothing.

Source map

Component	Path
Request parsing and validation	`crates/issuerd-protocol/src/ciba.rs`
Backchannel auth + approval handlers	`crates/issuerd-server/src/routes/oidc.rs` (`ciba_auth_handler`, `ciba_approve_handler`)
Polling in the token endpoint	`crates/issuerd-server/src/routes/oidc.rs` + `crates/issuerd-server/src/ciba_step_up.rs` (`urn:openid:params:grant-type:ciba`)
Exact-operation approval page	`crates/issuerd-server/src/ciba_approval.rs`
Durable grants and atomic execution	`crates/issuerd-core/src/mcp_step_up.rs`, `crates/issuerd-storage/src/step_up.rs`, migration `018_mcp_step_up_grants.sql`
Confidential TypeScript acceptance	`examples/mcp-admin/client/src/ciba.ts`, `step-up.ts`
DPoP binding of the issued token	`crates/issuerd-server/src/dpop.rs`
Discovery advertisement	`crates/issuerd-protocol/src/discovery.rs` (`backchannel_authentication_endpoint`)
